Mantis X Pro electric off-road bike
Model Rawrr Mantis X Pro
Rawrr's fastest electric off-road bike: 15 kW peak, 0–48 km/h in 2.6 seconds, adjustable suspension and app-tunable ride modes, on a 6061 aluminium frame.
- 15 kWPeak power
- 105 km/hTop speed
- 2.6 s0–48 km/h
- 100 km*Range (Eco mode)
- 2.52 kWh72 V battery
- 72 kgWeight with battery
R89,500.00incl. VATR77,826.09 excl. VAT
*Up to 100 km in Eco mode, manufacturer estimate. Real range depends on rider, terrain, speed and mode. Off-road use only.
- Supplied and supported by Uni-E, with branches in 4 cities
Overview
The fastest Mantis yet.
The Rawrr Mantis X Pro is the fastest bike in the Rawrr range. Its 15 kW PMSM motor (5 kW continuous) drives the rear wheel through a gearbox and chain, reaching 105 km/h and accelerating from 0 to 48 km/h in 2.6 seconds. A 72 V, 2.52 kWh lithium-ion battery gives up to 100 km in Eco mode.*
The frame is 6061 aluminium. Rawrr added a custom rear linkage for sharper handling, adjustable front and rear suspension, and 4-piston hydraulic disc brakes with 220 mm rotors front and rear to match the extra power. The controller is fully tunable, with Eco, Sport and Race modes and app control.
The Mantis X Pro is an off-road bike. It is not road legal: ride it on private land, trails and tracks, and always wear a helmet and protective gear.
Figures from Rawrr (riderawrr.com), converted to metric.
Key features
Built for trails, tracks and berms.
0–48 km/h in 2.6 s
Top speed of 105 km/h.
72 V, 2.52 kWh battery
Lithium-ion, up to 100 km in Eco mode.*
Adjustable suspension
200 mm front fork travel and a custom rear linkage.
4-piston hydraulic brakes
220 mm discs front and rear, DOT 4 fluid.
Tunable ride modes
Eco, Sport and Race, with app control and an LCD display.
Technical specifications
Rawrr Mantis X Pro
Figures supplied by the manufacturer.
Performance
- Peak power
- 15,000 W (15 kW)
- Continuous power
- 5,000 W (5 kW)
- Top speed
- 105 km/h
- Acceleration (0–48 km/h)
- 2.6 s
- Maximum torque
- 390 N·m
- Range
- Up to 100 km (Eco mode)*
- Climbing ability
- 45°
- Maximum rider load
- 100 kg
Motor and battery
- Motor
- PMSM
- Drive
- Gearbox and chain
- Battery
- Lithium-ion, 72 V, 2,520 Wh
- Ride modes
- Eco, Sport, Race
- Display
- LCD
- Controller
- Fully tunable, app control
Chassis
- Frame
- 6061 aluminium alloy
- Front fork travel
- 200 mm
- Rear suspension travel
- 70 mm
- Suspension
- Adjustable front and rear, custom rear linkage
- Brakes
- 4-piston hydraulic disc, DOT 4 fluid
- Brake discs (front / rear)
- 220 mm / 220 mm
- Rear tyre width
- 89 mm
Dimensions and weight
- Overall length
- 1,880 mm
- Overall height
- 1,130 mm
- Handlebar height
- 1,100 mm
- Seat height
- 864 mm
- Wheelbase
- 1,245 mm
- Ground clearance
- 325 mm
- Weight with battery
- 72 kg
Use
- Road use
- Not road legal. Off-road use only
